DIV 38 Alarm
COMEX diving bells feature a DIV 38 shuttle valve fitted on the breathing panel.In case of lack of breathing gas coming from the umbilical, the shuttle valve automatically by-passes the umbilical and puts in use the gas coming from the onboard gas...
More details
Manual System - Open
COMEX standard Guide Line Release System is made of blocks welded on the bell cage featuring bronze bushings.  Two types of release system are available: • Manually operated, • Hydraulically operated from inside the bell....
More details
Bell Ballast Release System Bushings
The ballast release system is designed to comply with DNV rules according to buoyant ascent of the bell. The ballast is hold by 2 short flat bars and 2 long chains.Each bar and chain is connected to the bell by a release system that can be...
More details
Heating Elements
• Designed for sea water heating• Material:- Inconel heating element- Stainless steel flange- Teflon spacer• Sealing: IP 679Other specification on request
More details
DIV 51 Flow Fuse Repair Kit
This Flow limitor closes automatically in order to avoid an unwanted discharge of the pressure in a hyperbaric vessel due to a pipe breakage It is not anymore manufactured Only seal kits are available. Also old flow fuses (if not in too bad...
More details
EV100 Oxygen Solenoid Valve
This valve is designed to be fitted in an oxygen automatic addition system• Brass & steel body• O2 max. pressure: 100 bar• Seat: PCTFE• Cleanliness: O2 usePower supply: 24VDC
More details
DIV 38 Shuttle Valve
The Shuttle valve is designed to supply the breathing mixture to the divers in normal and emergency case.In Normal use, the user outlet is supplied by the umbilical.In case of accidental cut off of the supply coming from the surface, the shuttle...
More details
D110 Pressure Reducer
The D110 Pressure Reducer is specially designed for Bell O2 add. • Watertight • Brass body • Back-up pressure: 250 bar • Outlet pressure: 2 to 5 bar • Seat: PCTFE • Inlet/outlet: 1/4” BSP •...
More details
D108 Pressure Reducer
D108 Pressure Regulator works like the D106 Pressure Regulator, but the diaphragm is replaced by a piston to allow outlet pressure up to 50 bar• Brass body• Back-up pressure: 250 bar• Outlet pressure: 2 to 50 bar• Seat:...
More details
D107 Pressure Reducer
The D107 Pressure Reducer is specially designed for Bell analysis line. • Watertight • Brass body • Back-up pressure: 250 bar • Oulet pressure: 0.1 to 1.5 bar • Seat: PCTFE • Inlet/outlet: 1/4” BSP •...
More details
D106 Pressure Reducer
The D106 Pressure Reducer is specially designed for DDC analysis line. • Brass body • Back-up pressure: 250 bar • Oulet pressure: 0.1 to 1.5 bar • Seat: PCTFE • Inlet/outlet: 1/4” BSP • Cleanliness: O2 use
More details
F1509L
The F1509L filter is used in order to protect the downstream equipment against dirt and foreign particles. It is easily assembled with D79/L and D110 Pressure Reducers thanks to a special Adjustable fitting.Note : F1509/L14 is sometimes seen in...
More details
D79/L Pressure Reducer
• Brass body• Back-up pressure: 250 bar• Outlet pressure: 7 to 52 bar• Threaded hole: 3/8’’ BSP• Seat: brass and PCTFE• Cleanliness: O2 use
More details
F1526 Filter (Intergrabloc)
The F1526 Filter is used exclusively in INTEGRABLOC circuits in order to protect the downstream equipment against dirt and foreign particles. It is mainly used assembled with the D104 regulator. The filter cartridge can be replaced without...
More details
D104 Pressure Reducer (D79/L Cx Integrabloc)
• Brass body• Back-up pressure: 250 bar• Outlet pressure: 7 to 52 bar• Seat: brass and PCTFE• Cleanliness: O2 use
More details
RO 52 Drain Valve
• Brass body• Working pressure: 250 bar• Seat: PCTFE• Cleanliness: O2 cleaned
More details
Integrabloc System
Principle: These modular elements include the main components of a gas panel: filters, regulators, dump valve, safety valves, non-return valves, valves, solenoid valves ... also input and output blocks, connection blocks that can receive pressure...
More details
RO48 Integrabloc HP Valve
• Brass body• Working pressure: 250 bar• Seat: PCTFE or copper for O2• Cleanliness: O2 cleaned
More details
Gas Storage Valves
Onboard bottle valves, Tube and quad valves are available• Brass body• Working pressure: 200 bar
More details
Regeneration Circuitry Ball Valve
• Body: carbon steel• Working pressure: 50 bar• Seat: PTFE and nitrile• Cleanliness: O2 cleaned• Working temperature: normal 60°C or high 200 °C
More details
Toilet Ball Valve
• Stainless steel• Heliox working pressure: 45 bar• Full bore: 2’’
More details
Perrin HP Ball Valve
A lot of valves used on COMEX diving systems are obsolete and no more available. Nevertheless, for most of them, seal/repair kits are still available.
More details
APOLLO Spring Loaded Valve
• Stainless steel body• Working pressure: 140 bar• Seat: PTFE• Cleanliness: O2 cleaned
More details
63 Bar Monobloc Ball Valve
Ball valve, monobloc designFull bore atex Ex II 3 GDLocking device handleBody & ball: stainless steel 316LSeats: RPTFE• No seal kit• Economical serie
More details
125 Bar SS Ball Valve
Stainless steel 316LSeats: RPTFEWorking pressure: 125 bar3 pieces - full boreEasy automation and maintenance.• ISO 5211 top flange• Antistatic devices• Fire safe tested API 607 REV. 4• Atex EX II 2 GD• Cleanliness: O2 cleaned
More details
